Item Type: Battery Testers
Hardware Version: Newest
Software Version: Newest
Model Name: BT260
Power: 8W
Voltage: 12V
External Testing Certification: ce
Item Length: 25cm
Item Width: 15cm
Item Height: 8cm
Item Weight: 1.2kg
Material Type: metal and plastic
Electronic: No
Brand Name: AUTOOL
Special Features: Line connection
Item Type: Car Diagnostic Power Probe
Function: Automotive Circuit Voltage Test
Feature 1: 6-30V Car Battery Tester
Feature 2: Automotive Tool


Product description

bt260

The AUTOOL BT260  is the best electrical tester for reducing diagnostic time in all 6 to 30 volt .



Vehicle electrical systems. After a simple hook-up of the tool to the vehicle's battery.



106ec609-4f8f-4b32-a950-805075fb920c





Feature:



Multi-language support: English  German  French  Russian Spanish Italian  Portuguese



Integrate LED flashlight on the head, let us work in dark condition easily



All the clips and cable were made from copper, improve BT-260 stability during operation



Testing for continuity with its built-in auxiliary ground lead.



By depressing the power switch, conduct a positive or negative battery current to the probe

tip for testing the function of an electrical component without the use of jumper wires.



Testing for poor ground contacts instantly without performing voltage drop tests.



The tool is  also short-circuit protected; its internal circuit breaker will trip if it becomes overloaded.



Following and locate short circuits without wasting fuses.



The tool's long cable allows you to  test along the entire length of the vehicle without constantly searching for suitable vehicle grounds.




3a19215e-729d-4c46-84f4-38f97f9932a6



How to change language?



a: Press the function key(a yellow button on body of BT260) 3 times to visit loudspeaker icon



b: Then press and hold upward button,meanwhile press function key 5 times to visit "Language" menu



c:  Press funtion key to choose the language you'd like to,then press and hold the key last 3 seconds, the language setting is done



d:  Press the function key 1 time and go back to main menu



BT260



Parameter:



1)Display: TFT color display (160 x 128 dpi)


2)Operating Temperature: 0 to 60°C (32 to 140 F)


3)Storage Temperature: -40 to 70°C (-40 to 185 F)


4)External  Power:  12.0  or  24.0  V  power  provided  via  vehicle battery


5)Dimensions(L*W*H): 126 mm (4.96”)x46.5 mm (1.83”)x35 mm (1.38”)



6)  NW: 0.105kg (0.23lb),   GW: 0.726 kg(1.6lb)



IMG_8025IMG_8036



d221a0ac-83e2-459e-932c-deff836448bb



HTB1pibVnj3z9KJjy0Fmq6xiwXXaI




Package Included:

1x Unit


1x User’s Manual.


1x Cigarette lighter adapter.


1x Battery hookup clips


1x Probe tip



1x 20ft. extension cable.
